Add Hand Gesture Recognition in One Line of Code

A reusable, plug-and-play Python module extracting MediaPipe's power into a dead-simple API. Detect arithmetic gestures, finger counts, and custom actions instantly.

pip install mp-gesture-lib

View Examples

quickstart.py

from mp_gesture_lib import GestureDetector
import cv2

# 1. Initialize with bundled models
detector = GestureDetector()
cap = cv2.VideoCapture(0)

while cap.isOpened():
    ok, frame = cap.read()

    # 2. Detect gesture with one call
    result = detector.detect(frame)

    # 3. Use the result!
    print(f"Detected: {result.gesture}")
    print(f"Confidence: {result.confidence}")

    cv2.imshow("Demo", result.annotated_frame)
    if cv2.waitKey(1) == 27: break

Why MP_Gesture_Lib?

Designed for developers who want to integrate computer vision without becoming CV experts.

🚀

Zero Configuration

No model paths required. Bundled models are auto-discovered and loaded instantly. Just import and go.

🧠

Multi-Model Hierarchy

Combines custom user ML models, bundled fallback models, and geometry-based rules into a single priority pipeline.

🛠️

Rule-Based Fallbacks

Includes built-in geometry rules for advanced gestures (like "plus" and "multiply") and precise 1-10 finger counting.

Supported Gestures

The library detects standard numbers and arithmetic operations out-of-the-box.

Plus

Rule-based

Minus

ML Model

Multiply

Rule-based

Divide

ML Model

Equal

ML Model

Clear

ML Model

Zero (0)

ML Model

🔢

Numbers 1-10

Finger Count

Detects extended fingers with direction-awareness.

Usage Examples

Flexible patterns for any integration scenario.

Uses the bundled auto-discovered models. Perfect for quick starts.

minimal.py

import cv2
from mp_gesture_lib import GestureDetector

# Automatically loads bundled models
detector = GestureDetector()
cap = cv2.VideoCapture(0)

while cap.isOpened():
    ok, frame = cap.read()
    result = detector.detect(frame)

    # "plus" 1.0 / "3" 1.0 / "minus" 0.91
    print(result.gesture, result.confidence)

Load your own `.task` file. The custom model is queried first; bundled models act as a fallback.

custom_model.py

from mp_gesture_lib import GestureDetector

detector = GestureDetector(
    model_path="my_custom_gestures.task",
    ml_threshold=0.80,      # stricter confidence requirement
    draw_landmarks=False,   # faster, skips skeleton drawing
    num_hands=2             # track up to 2 hands
)

Working with PIL, torchvision, or other libraries that use RGB instead of OpenCV's default BGR format.

rgb_input.py

# Assuming 'rgb_frame' is a numpy array in RGB format
# (e.g., from PIL.Image or similar)

result = detector.detect(rgb_frame, input_is_rgb=True)

# The returned annotated_frame will ALSO be in RGB format
# matching the input format.

API Reference

Clean, typed, and predictable interface.

GestureResult Dataclass

Field	Type	Description
`gesture`	str	Gesture name (e.g. `"plus"`, `"3"`) or `"unknown"`.
`confidence`	float	0.0–1.0 (1.0 for rule-based, model score for ML, 0.0 for unknown).
`raw_label`	str	Internal debug label (e.g. `"ml:minus"`, `"rule:plus"`).
`annotated_frame`	np.ndarray \| None	Input frame with hand skeleton drawn (if `draw_landmarks=True`).
